stainless steel swivel castor fork with brake Ø100mm top plate 80KG
Product description
Quality & Service since 1946
Quality & Service since 1946
Our quality is creating an easier work-life for the user of the wheel.
Every user and application has different needs. Let us know how we can help you to become a satisfied customer.
Industrialwheels.com is the range of the most popular wheels from our group of companies. Over two hundred fifty employees focus on manufacturing and developing high-quality wheels for the European market.
Product information
- SKU 396008103
- EAN 8718116175339
Specifications
- Wheel diameter (mm) 100
- Load capacity (kg) 80
- Size of top plate (mm) 95x67
- Topplate hole centres (mm) 74x44
- Mounting hole diameter (mm) 8,5
- Swivel offset (mm) 42
- Fitting Plate mounting
- Fork material Stainless steel AISI 304
- Thickness top plate 2
- Fork type Swivel fork and brake
- Brake Brake blocks both the turning and swivelling movement of the wheel
- Thickness fork legs 2
- Fork width (inner) 42
- Fork height 85
- Axle bore-Ø in fork legs 10
- Series 39008
