swivel castor, Ø 65 mm, all-polyamide (PA6) wheel, 100KG

Product description

transport swivel castor made of pressed sheet steel, plate mounting, fully polyamide (PA6) wheel, sliding bearing, Wheel Ø 65mm, 100KG

Wheel: all-polyamide (PA6) wheel, sliding bearing,

Advantages: Polyamide wheels have low rolling resistance, offer good handling on flat surfaces, are impact and shock resistant and corrosion resistant.

Applications: Industrial trolleys, material handling in factories, waste containers, transport containers, metal and chemical plants, medium-load roll containers, tool trolleys, warehouse trolleys.

Suitable substrate: Hard and flat such as tiles, cement and coatings.
Suitable environment : Dry and not permanently damp. With various chemicals and saturated steam.

Quality & Service since 1946

Quality & Service since 1946

Our quality is creating an easier work-life for the user of the wheel.
Every user and application has different needs. Let us know how we can help you to become a satisfied customer.

More information

Industrialwheels.com is the range of the most popular wheels from our group of companies. Over two hundred fifty employees focus on manufacturing and developing high-quality wheels for the European market.

swivel castor, Ø 65 mm, all-polyamide (PA6) wheel, 100KG

transport swivel castor made of pressed sheet steel, plate mounting, fully polyamide (PA6) wheel, sliding bearing, Wheel Ø 65mm, 100KG

  • We want to make your work-life easier Tooltip Just tell us what you need
  • Fast delivery
  • 3D CAD Models
  • Engineering service

Product information

  • SKU 146390650
  • EAN 8718116192190

Specifications

  • Non marking tread No
  • Wheel diameter (mm) 65
  • Wheel width (mm) 30
  • Load capacity (kg) 100
  • Overall height (mm) 97
  • Size of top plate (mm) 105x80
  • Topplate hole centres (mm) 9
  • Swivel offset (mm) 37
  • Swivel Radius 69
  • Tread description Polyamide (PA6) wheels
  • Castor wheel type Swivel castor
  • Fitting Plate mounting
  • Fork material Galvanised
  • Fork Swivel fork with plate fitting made of pressed galvanised sheet steel. With central bolt double ball race in swivel head and dust seal
  • Series 46.39
