Black swivel castor, Ø 50mm, thermoplastic rubber grey non-marking, 50KG

Product description

Black apparatus swivel castor from pressed steel, bolt hole, thermoplastic rubber gray non-marking, precision ball bearing, Wheel-Ø 50mm, 50KG

Black apparatus swivel castor thermoplastic (TPR) non-marking wheel


housing / bracket: pressed steel, double ball race in swivel head, black finish, blue passivated, bolt hole
wheel: thermoplastic rubber gray non-marking, with wheel centre from polypropylene, precision ball bearing,

Benefits: Versatile use for light transport in e.g. offices, warehouses, shops and institutions. Low noise, shock and vibration damping. Castor for light duty applications. Less suitable for prolonged use under maximum static load.

Applications: Bedside cabinets, computer tables, display stands, dustbins, file cabinets, garment stands, greeting card dispensers, housekeeping carts, I.V.-poles, newspaper dispensers, sales counters, small furniture, sports equipment.

Suitable surface: Smooth surface or surface with small irregularities. Non-marking tire for use on ceramic tiles, linoleum, etc.
Suitable environment: Dry and not permanently humid. For mild acids and alkalics.

Quality & Service since 1946

Quality & Service since 1946

Our quality is creating an easier work-life for the user of the wheel.
Every user and application has different needs. Let us know how we can help you to become a satisfied customer.

More information

Industrialwheels.com is the range of the most popular wheels from our group of companies. Over two hundred fifty employees focus on manufacturing and developing high-quality wheels for the European market.

Black swivel castor, Ø 50mm, thermoplastic rubber grey non-marking, 50KG

Black apparatus swivel castor from pressed steel, bolt hole, thermoplastic rubber gray non-marking, precision ball bearing, Wheel-Ø 50mm, 50KG

  • We want to make your work-life easier Tooltip Just tell us what you need
  • Fast delivery
  • 3D CAD Models
  • Engineering service

Product information

  • SKU 320884500Z
  • EAN 8718116222156

Specifications

  • Non marking tread Yes
  • Wheel diameter (mm) 50
  • Load capacity (kg) 50
  • Overall height (mm) 69
  • Swivel Radius 25.0
  • Bearing type Ball bearing
  • Hardness of tread 90° Shore A
  • Tread description Grey thermo (TPR) rubber
  • Temperature 0 / +40°C
  • Castor wheel type Swivel castor
  • Fitting Bolt hole fixing
  • Fork material Galvanised
  • Bolt hole diameter 11
  • Series 32.88Z
  • Tread Solid rubber
