stainless steel fixed castor fork Ø200mm top plate 300kg
Product description
Quality & Service since 1946
Quality & Service since 1946
Our quality is creating an easier work-life for the user of the wheel.
Every user and application has different needs. Let us know how we can help you to become a satisfied customer.
Industrialwheels.com is the range of the most popular wheels from our group of companies. Over two hundred fifty employees focus on manufacturing and developing high-quality wheels for the European market.
Product information
- SKU 296008200
- EAN 8718116181644
Specifications
- Wheel diameter (mm) 200
- Load capacity (kg) 300
- Size of top plate (mm) 135x110
- Topplate hole centres (mm) 105x80
- Mounting hole diameter (mm) 11
- Fitting Plate mounting
- Fork material Stainless steel AISI 304
- Thickness top plate 3
- Fork type Fixed fork
- Fork 296.008
- Thickness fork legs 3
- Fork width (inner) 61
- Fork height 132
- Axle bore-Ø in fork legs 12
- Series 96008
