swivel castor, Ø 200 mm, Phenol wheel, 350KG

Product description

wheel

Wheel: Made of high-quality Phenol resin for temperatures up to +280° C, highly impact-resistant hard running surface, Sliding bearing
Fork: Stainless AISI 304 fork with double ball race in the swivel head. swivel head with heat-resistant grease, plate fastening.

Stainless steel For various applications up to 280° C.

Quality & Service since 1946

Quality & Service since 1946

Our quality is creating an easier work-life for the user of the wheel.
Every user and application has different needs. Let us know how we can help you to become a satisfied customer.

More information

Industrialwheels.com is the range of the most popular wheels from our group of companies. Over two hundred fifty employees focus on manufacturing and developing high-quality wheels for the European market.

swivel castor, Ø 200 mm, Phenol wheel, 350KG

wheel

Enter the number of articles below and click

Ok

  • We want to make your work-life easier Tooltip Just tell us what you need
  • Fast delivery
  • 3D CAD Models
  • Engineering service

Request OE part

Download PDF

Chemical resistance

Product information

  • SKU 194760200
  • EAN 8718116112402

Specifications

  • Non marking tread Yes
  • Wheel diameter (mm) 200
  • Wheel width (mm) 50
  • Load capacity (kg) 350
  • Overall height (mm) 233
  • Size of top plate (mm) 135x110
  • Topplate hole centres (mm) 105x80
  • Mounting hole diameter (mm) 11
  • Swivel offset (mm) 56
  • Swivel Radius 156
  • Bearing type plain bearing
  • Tread description Heat-resistant wheel made of phenolic resin for temperatures up to 300°C.
  • Temperature -40 / +280°C
  • Castor wheel type Swivel castor
  • Fitting Plate mounting
  • Fork material Stainless steel AISI 304
  • Fork 194
  • Series 94.76 Heat-resistant Phenol wheel
