swivel castor fork with brake Ø100mm top plate 200KG
Product description
Quality & Service since 1946
Quality & Service since 1946
Our quality is creating an easier work-life for the user of the wheel.
Every user and application has different needs. Let us know how we can help you to become a satisfied customer.
Industrialwheels.com is the range of the most popular wheels from our group of companies. Over two hundred fifty employees focus on manufacturing and developing high-quality wheels for the European market.
Product information
- SKU 184003103
- EAN 8718116109136
Specifications
- Wheel diameter (mm) 100
- Load capacity (kg) 200
- Size of top plate (mm) 105x86
- Topplate hole centres (mm) 80x60
- Mounting hole diameter (mm) 9
- Swivel offset (mm) 40
- Fitting Plate mounting
- Fork material Galvanised
- Thickness top plate 4
- Fork type Swivel fork and brake
- Fork Swing fork for intensive industrial use with plate fitting made of pressed galvanised sheet steel. With central bolt double ball race in swivel head and dust seal
- Brake Brake blocks both the turning and swivelling movement of the wheel
- Thickness fork legs 3
- Fork width (inner) 52
- Fork height 92
- Axle bore-Ø in fork legs 10
- Series 84003
